BEC
/ BATTERY METERS /CHECKERS / RC GADGETS
|
|
ITEM
|
Decription
|
Price
|
|
|
SKY
POCKET SERVO TESTER- NEW!
The Pocket Servo Tester allows the user to
test and exercise servos and set up a model without
requiring the use of a transmitter and receiver. The
Servo Tester allows the user to control a servo directly,
to determine its neutral position and to cycle it automatically
for break-in and testing.
The Servo Tester offers small size, low power, high
reliability and easy operation. It is easy to use, practical
and can test most parameters that interest users. Controlled
by an SCM, it has good stability and high accuracy.
It is very adaptable to different power sources: it
can be used on a four-cell dry battery, NiCd or NiMH
pack; or it can be connected directly to a UBEC or ESC.
-Input: DC 4.8 to 6.0V
-Output signal: 1.5ms±0.5ms
-Size: 16.5×32×0.98mm.
-Weight: 3.8g (0.14 oz)
-Adjustment methods: manual, neutral, automatic.
Note:
* You may feel the knob is a little tight at the neutral
position when turning over the center, this is not a
problem but deliberately designed to work this way,
so as you can feel where the neutral position is during
testing. |
|
|
|
|
HOBBYWING
3A UBEC (Switching) - NEW!
The 3A-UBEC is a switch-mode DC-DC regulator
supplied with a 2-6 cells lithium battery pack (or 5-18
cells NiMH /NiCd battery ), it outputs a consistent
safe voltage for your receiver, gyro and servos. It
is very suitable for RC helicopter. Compared with the
linear mode UBEC, the overall efficiency of the switch-mode
UBEC is much higher.
Designed with an advanced switch mode DC-DC regulator
IC. The output is powerful even working with 4 to 6
cells Lipo battery. Battery polarity reversal protection.
A metal shield covers almost all the electronic components,
and a specially made filter is attached with the output
wires to significantly reduce the electromagnetic interference.
The working status is shown by an indicator (LED), lights
when the output is in normal range.
-Output Voltage: 5V@3A or 6V@3A (Changeable with an
output-voltage select switch )
-Continuous output current: 3 Amps
-Input: 5.5V-26V (2-6 cells lithium battery pack or
5-18 cells NiMH /NiCd battery)
-Size: 43mmx17mmx7mm (LxWxH)
- Weight: 11g |
|
|
|
|
HOBBYWING
8A UBEC (Switching) - NEW!
Designed with an advanced switch mode DC-DC
regulator IC. The output current is very large. With
the output short-circuit protection function. -A metal
shield covers almost all the electronic components,
and a specially made filter is attached with the output
wires to significantly reduce the electromagnetic interference.
Automatically detects the number of the lithium battery
pack (2 cells or 3 cells). Shows the battery capacity
with 4 indicators (LEDs). Shows the working status with
an indicator (LED), lights when the output is in normal
range. There are 2 output leads to reduce the resistance
when connecting the UEBC to the receiver.
-Output Voltage: 5V or 6V (Changeable with an output-voltage
select switch )
-Continuous output current: 8 Amps
-Burst output current: 15 Amps
-Input: 6V-12.6V (2-3 cells lithium battery pack)
-Quiescent current: 60mA
-Size: 42mmx39mmx9mm (length x width x height) -Weight:
36g |
|
|
|
|
VELOCITY
SERVO REVERSER - NEW!
Reverse your Servo Signal with this unit
to overcome the "Dual Elevator" Servo problems.
Direct link between the servo and receiver to reverse
the direction of the "other" servo sharing
the same channel.
Weight : 4g approx
Suitable Servos : 1520us and 760us
Input : 3V ~ 12.6V |
|
|
|
|
NEW! HYPERION Emeter2 Phase Tachometer
for Brushless Motors
Product Code : HP-EM2-TACHBL
This one is a beauty! Just attach inline
on one of the three brushless motor wires (solder up
a male/female connector adapter for convenience) and
log motor rpm extremely accurately throughout the motor
run. You need to know how many magnets are in your motor
to configure the RDU, but even if you don't know the
Emeter can be connected and RDU rpm compared with the
Emeter tach. Makes it a snap to set it up right, every
time... And this unit is NOT plagued by the problems
found in some other brands. It's rock solid!
Latest Note:
Suitable
for the following RPM Sensing for your governor controls.:
-MIKADO VBAR
-SKOOKUM 720 Version 3 |
|
|
|
|
RC LOGGER
Digital Pitch Gauge
A perfect tool for accurate blade and
pitch alignment which is essential for flybarless
systems. Measurement is extremely fast and precise.
Features:
- Amazingly convenient.
- On/Off button allows you to conserve battery life.
- Hold button will stop the sensor from updating the
angle that it senses. Useful for those who are working
in an unstable environment.
- Zero button allows you to set "0" at any given position
of the sensor.. This allows you to see your pitch
travel at any interval.
- Digital sensor is removable from the blade clip
portion (attached by 2 magnets), allowing you to use
it for any of your household angle-sensing needs!
- Digital sensor is capable of being calibrated. If
your sensor isn't seeing 90 degrees as 90 degrees,
calibrate it and it will.
|
|
|
|
|
Hyperion
EOS SENTRY
Multi-Purpose Battery Checker
(with percentage reading)
Know your packs! The EOS
SENTRY is a quick, convenient, easy-to-use device.
It shows at a glance the remaining capacity in your
battery pack, cell balance, and other information
you need to get the best performance and reliability
from your batteries, and avoid costly mistakes.
The large LCD display and capacity graphs make it
easy on your eyes. And the low price of the SENTRY
compared with the high cost of batteries make it a
sure money-saving addition to every toolbox at the
flying field, boat races, or car race track.
Discharge of LIPO in particular beyond 80% of capacity
is sure to damage them. Be sure to use the EOS Sentry
after flights (or laps) from time to time. If you
see 19% or less capacity remaining, reduce the Transmitter
timer until at least 20% is shown remaining at the
end of each flight or race...
|
|
|
Click for above for full image
|
ACME LIPO
MONITOR/ANALYZER
Up to 8S Lipo Batteries
(USB Version)
With its internal resistance measurement
function, you can preliminary select the lithium batteries
Specifications:
- Displays graph of the voltage/current via the USB
port or UART port when charger working
- Displays unit voltage, capacity, temperature
- Measure internal resistance of lithium battery at
the state of 2A, 4A and 1KHz
- Can be used as a temperature gauge, its measure
range is 0-100°C tolerance:±1°C
- Built-in 1200mAh lipo battery, it can work for continuously
more than 10 hours
- Over voltage and reverse polarity protect function
- Standby power consumption: <2mA
|
|
|
Click for above for full image
|
ACME LIPO
MONITOR/ANALYZER
Up to 8S Lipo Batteries
(SERIES/PC Port Version)
With its internal resistance measurement
function, you can preliminary select the lithium batteries
Specifications:
- Displays graph of the voltage/current via the USB
port or UART port when charger working
- Displays unit voltage, capacity, temperature
- Measure internal resistance of lithium battery at
the state of 2A, 4A and 1KHz
- Can be used as a temperature gauge, its measure
range is 0-100°C tolerance:±1°C
- Built-in 1200mAh lipo battery, it can work for continuously
more than 10 hours
- Over voltage and reverse polarity protect function
- Standby power consumption: <2mA
|
|
|
|
|
CellLog
8S
Cell Voltage Monitoring & Recording
Specifications:
Lithium (LiPo/LiIo/LiFe) battery cell
count: 2–8 series
Pack voltage range: 4.0–43.0 V DC (with USB to 1.0V)
Alarm pack voltage range: 0.1–4.3 V DC
Cell voltage range: 1.3–4.9 V DC
Alarm cell voltage range: 1.3–4.9VDC
Voltage display resolution: 1mV
Voltage display resolution: 5mV
Current loading of test: 8mA
Maximum voltage for alarm port: 50VDC
Current drain for alarm port: <500mA
Log Files storage: 16Mbit (36 hours)
PC Connect: USB port
Weight: 18 g
Dimensions (LxWxD): 62x39x12 mm
Features:
• Accurate cell voltage monitoring
and measurement to three decimal places.
• Small size with many functions, backlight 128x64
LCD and tone alarm
• Simple, easy to use interface.
• Measures 2-8S Li battery individual voltage and
can also measure NiMH, NiCd, and Pb battery pack voltage
• Settings include Individual Voltage Alarm or
Pack Voltage Alarm, Overvoltage Alarm, Low voltage Alarm,
Differential Voltage Alarm, and Time Over Alarm. An
extra alarm output is integrated which can be controlled
by the users.
• LiPo/LiIo/LiFe battery types voltage monitor
mode can be selected separately.
• CellLog 8S has been 100% calibrated and also
supports user calibration.
•CellLog 8S has a 16Mbit flash storage, which can
log offline charge and discharge data for 36 hours.
•Firmware can be updated as new features are added
and improved by the USB port. The CellLog 8S also support
the “logview” software and can display, plot and analyze
the charge and discharge data by it. (See detailed information
about logview in the following website. |
|
|
|
|
LIPO METER
(LED Voltage Reader)
This 2 to
6 cell lipo battery meter weighs only 5.8g and is
essential for all electric flying. No one wants to
fly with a half charged or empty battery and having
this little meter ensures you wont. It can be installed
or just used prior to each flight. The unit checks
the voltage and balance of each cell and then gives
a total voltage reading. Very easy to use, just plug
into your battery JST plug and the device does the
rest.
Specifications:
Weight 5.8g
Dimension 19.05 x 50 x 10.7mm
Input Voltage 0.01v - 4.5v per cell
Precision +/- 0.03v
|
|
|
|
|
Lipo Alarm/
Double Beeper with LED indicators
FOR 2S/3S/4S Lipo Batteries
4 GREEN LEDs for up to 4 cells (Operation
Mode)
4 RED LEDS for up to 4 cells (Low Voltage)
2S : 2 Green LED in operation
3S : 3 Green LED in operation
4S : 4 Green LED in operation
When voltage <3.3V/cell, the audible buzzer will
go off and buzz with RED LED Lights.
Specifications:
Weight 5.8g
Dimension 25 x 39 x 10.7mm
Input Voltage 0.01v - 4.5v per cell
Double Beepers for extra high decibel alarm
|
|
